CVP-509/505/503/501 Owner’s Manual
99
Connections
– Using Your Instrument with Other Devices –
Before connecting the instrument to other electronic components, turn off the power of all the
components. Also, before turning any components on or off, make sure to set all volume
levels to minimum (0). Otherwise, electrical shock or damage to the components may occur.
CVP-509/505
CVP-503/501
CVP-509 Only
Front (keyboard side)
Right (higher-k
e
y
side)
Left (lo
w
er-k
e
y
side)
Front (keyboard side)
Right (higher-k
e
y
side)
Left (lo
w
er-k
e
y
side)
