CAPACITY & PERFORMANCE DATA
UNIT MODEL
NUMBER
COOLING
CAPACITY 95°F
UNIT CHARGE
WEIGHT HCFC-22
RATED CFM
SENSIBLE
TOTAL RATIO
SOUND RATING
PAC036H1081A
33,000
3.7 Lbs.
1,200
0.74
8.4
PAC048H1081A
47,000
7.0 Lbs.
1,500
0.68
8.4
PAC060H1081A
55,000
7.6 Lbs.
1,600
0.65
8.4
BLOWER PERFORMANCE DATA
UNIT SPEED
STATIC PRESSURE
PAC036H1081A
PAC048H1081A
PAC060H1081A
.1
.2
.3
.4
.5
.6
.7
.8
1837
1781
1720
1672
1607
1534
1443
1352
1243
1489
1468
1441
1412
1378
1336
1279
1204
1120
1238
1228
1216
1207
1180
1138
1088
1024
938
COMPRESSOR DATA
UNIT MODEL
PAC036H1081A
PAC048H1081A
PAC060H1081A
MANUFACTURER
Bristol
Bristol
Bristol
COMPRESSOR MODEL
H23A383DBEA
H23A543DBEA
H26A68QDBEA
RPM (50 Hz)
3,000
3,000
3,000
RATED LOAD AMPS
6.1
8.0
9.6
LOCK ROTOR AMPS
39.0
53.0
79.0
BRANCH CIRCUIT SELECTION
CURRENT (BCSC)
6.1
8.0
9.6
ELECTRICAL DATA - Packaged A/C (No Electric Heat)
MODEL
PAC036H1081A
PAC048H1081A
PAC060H1081A
Power Supply Volts / Phase / Hertz
380--415 / 3 / 50
Maximum Fuse Size (Amp)
15
20
20
Maximum Circuit Breaker Size (Amp)
15
20
25
Min. Wire Size (AWG) Copper
(75_C) Size -- Ft.
#14--0--80
#12--81--130
#14--0--60
#12--61--90
#12--0--60
#10--61--100
Total Input @ Rated Conditions
Running Amps
7.4
10.2
11.3
Running Watts
4,050
5,870
6,650
CONDENSER COIL DATA
MODEL
PAC036H1081A
PAC048H1081A
PAC060H1081A
Face Area, Sq. Ft.
9.25
11.24
11.24
Tube Diameter Inches
3/8
3/8
3/8
Rows Deep
1
2
2
Fins / Inch
18
15
15
