BHX024-060 Physical Data
Component
Models
BHX024
BHX036
BHX048
BHX060
Nominal Tonnage
2.0
3.0
4.0
5.0
ARI COOLING PERFORMANCE
Gross Capacity @ ARI A point (Btu)
24.9
35.3
49.2
58.8
ARI net capacity (Btu)
24.4
34.4
47.0
57.0
EER
12.0
11.5
11.3
11.0
SEER
16
15
15
14.5
Nominal CFM
800
1200
1600
1700
System power (KW)
2.0
3.0
4.2
5.2
Refrigerant type
R410a
R410a
R410a
R410a
Refrigerant charge (lb-oz)
7-10
10-4
12-4
12-0
ARI HEATING PERFORMANCE
47°F Capacity Rating (Mbh)
19.8
33.0
45.0
55.0
System Power (Kw/COP)
3.5
3.1
3.0
3.1
17°F Capacity Rating (Mbh)
11.1
18.9
27.2
32.4
System Power (Kw/COP)
2.1
2.0
2.1
2.1
HSPF (BTU/Watts-hr.)
8.0
8.0
8.0
8.0
DIMENSIONS (inches)
Length
49 1/8
49 1/8
49 1/8
49 1/8
Width
47 1/4
47 1/4
47 1/4
47 1/4
Height
33 1/2
33 1/2
41 1/2
41 1/2
OPERATING WT. (lbs.)
350
400
440
460
COMPRESSORS
Type
Scroll 2-spd
Scroll 2-spd
Scroll 2-spd
Scroll 2-spd
Quantity
1
1
1
1
CONDENSER COIL DATA
Face area (Sq. Ft.)
11.7
11.7
16.4
16.4
Rows
1
2
2
2
Fins per inch
20
20
20
20
Tube diameter (in.)
3/8
3/8
3/8
3/8
Circuitry Type
Interlaced
Interlaced
Interlaced
Interlaced
Refrigerant control
Orifice
TXV
TXV
TXV
EVAPORATOR COIL DATA
Face area (Sq. Ft.)
4.38
4.38
5.63
5.63
Rows
3
3
3
3
Fins per inch
15
15
16
16
Tube diameter
3/8
3/8
3/8
3/8
Circuitry Type
Interlaced
Interlaced
Interlaced
Interlaced
Refrigerant control
TXV
TXV
TXV
TXV
CONDENSER FAN DATA
Fan diameter (Inch)
22
22
22
22
Type
Axial
Axial
Axial
Axial
Drive type
Direct
Direct
Direct
Direct
No. speeds
2
1
2
2
Number of motors
1
1
1
1
Motor HP each
1/3
1/4
1/3
1/3
RPM
850/1100
1100
900/1100
950/1100
Nominal total CFM
2400
2400
3000
3000
DIRECT DRIVE EVAP FAN DATA
Quantity
1
1
1
1
Fan Size (Inch)
10 x 8
11 x 10
11 x 10
11 x 10
Type
Centrifugal
Centrifugal
Centrifugal
Centrifugal
No. speeds
1
1
1
1
Motor HP each
1/2
3/4
3/4
1
RPM
Variable
Variable
Variable
Variable
Frame size
48
48
48
48
FILTERS
Quantity - Size
2 - 22 x 14 x 1 2 - 22 x 14 x 1 2 - 22 x 14 x 1 2 - 22 x 14 x 1
