Unit typical duct applications, Unit typical slab on ground installation – York AFFINITY R-410A User Manual
Page 52
333495-YTG-C-0908
52
Johnson Controls Unitary Products
Unit Typical Duct Applications
Unit Typical Slab on Ground Installation
ROOF CURB
INSTALLATION
REAR DUCT
ROOF CURB
INSTALLATION
BOTTOM DUCT
SLAB ON GROUND
INSTALLATION
TO POWER SUPPLY
SUPPLY AIR
DUCT
RETURN AIR
DUCT
FIELD SUPPLIED
DISCONNECT SWITCH
LOCATED TO REAR OF UNIT
CONTROL WIRING
TO INDOOR
THERMOSTAT
