251934-YTG-G-0708
18 Johnson Controls Unitary Products
CONDENSER FAN DATA
Quantity 4 4 4
Fan diameter (Inch) 24 30 30
Type Prop Prop Prop
Drive type Direct Direct Direct
No. speeds 1 1 1
Number of motors 4 4 4
Motor HP each 1/3 3/4 3/4
RPM 850 870 870
Nominal total CFM 4000 5000 5000
BELT DRIVE EVAP FAN DATA
Quantity 1 1 1
Fan Size (Inch) 15 X 15 18 X 15 18 X 15
Type Centrifugal Centrifugal Centrifugal
Motor Sheave 1VP65 1VP65 1VP60 1VP60 1VP60 1VP75X 1VP75X
Blower Sheave BK110 BK090 BK110 BK090 1B5V94 1B5V110 1B5V94
Belt BX85 BX81 BX78 BX75 BX78 5VX840 5VX860
Motor HP each 5 7.5 7.5 10 7.5 10 15
RPM 1725 1725 1725 1725 1725 1725 1725
Frame size 184T 213T 213T 215T 213T 215T 254T
FILTERS
Quantity - Size
4 - 16 x 25 x 2
4 - 16 x 20 x 2 4 - 16 x 25 x 2
4 - 16 x 20 x 2 4 - 16 x 25 x 2
4 - 16 x 20 x 2
ZR180-300 Physical Data (Continued)
Component
Models
ZR180 ZR240 ZR300
Nominal Tonnage 15 20 25
