Omni 56K Plus Series User’s Guide
Command Sets 4-23
Table 4-16 Extended S-Registers "ATSn=x"
COMMAND BIT DEC HEX FUNCTION AND DESCRIPTION REF.
6-4 16-
112 10-70 Speaker volume control, increments of 32 in decimal
value. L0-7
S25= 0-255 0-FF Specify the time delay that DTR signal needs to be OFF
before it will be recognized, in 10 ms units. If S25=0,
the delay time is set to 4 ms. +000
S27= bit dec hex Bit mapped register. +156
0-2 Modem error control.
0 0 No error control. &K0
1 1 MNP4 + MNP3 (see also S41.0) &K1
2 2 MNP4 + MNP5 (see also S38.5, S41.0) &K2
3 3 V.42+MNP4 &K3
4 4 V.42 + V.42bis (compatible with &K2) (Default) &K4*
5 5 V.44 &K5
3-5 0 0 Flow control disabled. &H0
24 18 Hardware (RTS/CTS) flow control. (Default) &H3*
32 20 Software (XON/XOFF) flow control. &H4
40 28 Reserved. &H5
6-7 Signal quality.
0 0 No response to poor signal quality. *Q0
64 40 Retrain action taken if signal quality is poor. *Q1
128 80 Adaptive rate (auto fall-back /forward) when signal
quality changes. (Defaults) *Q2*
S41.2
192 C0 Disconnect when signal quality is poor. *Q3
S28= bit dec hex Bit mapped register. +068
0 0 0* Single line RJ-11 phone jack (Default) &J0*
1 1 Multiple phone/modem line, RJ12/RJ13 phone jack &J1
1 0 0* Panel key is normal (Default) *L0*
2 2 Panel key is locked *L1
2-3 0 0 Destructive, expedited break. &Y0
1 4 Non-destructive, expedited break. (Default) &Y1*
10 8 Non-destructive, un-expedited break. &Y2
4-5 0 0 No guard tone. (Default) &G0*
16 10 Reserved &G1
32 20 1800 Hz guard tone. &G2
6 0 0 DTE/DCE rate follows link rate. (See also S18, S44b6) &B0
64 40 DTE/DCE rate is fixed at the DTE setting, range from
300-460.8 Kbps. (Default, also see S18, S44b6)
&B1*
