Omni 56K Plus Series User’s Guide
4-22 Command Sets
Table 4-16 Extended S-Registers "ATSn=x"
COMMAND BIT DEC HEX FUNCTION AND DESCRIPTION REF.
2 2 Speaker is ON until carrier is detected. (Default) M1*
4 4 Speaker is always ON. M2
6 6 Speaker is ON after last digit is dialed out until carrier
detected. M3
3 0 0 DSR is always ON. (Default) &S0*
8 8 According to CCITT. (see also S44.4, S41.5) &S1
4 0 0 CD is always ON. &C0
16 10 CD tracks presence of data carrier. (see also S38.3)
(Default) &C1*
6-7 0 0 Assume DTR always On. &D0
64 40 108.1, DTR OFF-ON transition causes dial of the
default number. &D1
128 80 108.2 Data Terminal Ready, DTR OFF causes the
modem to hang up and return to command state.
(Default) &D2*
192 C0 108.2+RST, DTR OFF causes the modem to hang up
and reset the modem to profile 0 after DTR dropped. &D3
S23= bit dec hex Bit mapped register. +105
0 0 0 Command echo disabled. E0
1 1 Command echo enabled. (Default) E1*
1 0 0 Tone dial. (Default) T*
2 2 Pulse dial. P
2 0 0 Pulse dial make/break ratio = 39% / 61% (Default) &P0*
4 4 Pulse dial make/break ratio = 33% / 67% &P1
3-5 0 0 ATX0 (See result code table) X0
8 8 ATX1 X1
16 10 ATX2 X2
24 18 ATX3 X3
32 20 ATX4 X4
40 28 ATX5, error control result code is enabled. (Default) X5*
48 30 ATX6, error control result code is enabled. X6
56 38 ATX7, error control result code is enabled. X7
6 0 0 Display result code in numeric format. (see S35.7) V0
64 40 Display result code in verbose format. (Default) V1*
7 0 0 Modem returns result code. (Default) Q0*
128 80 Modem does not return result code. (see also S40.1) Q1
S24= bit dec hex Bit mapped register.
