Omni 56K Plus Series User’s Guide
4-20 Command Sets
Table 4-16 Extended S-Registers "ATSn=x"
COMMAND BIT DEC HEX FUNCTION AND DESCRIPTION REF.
0,1 0 0 Even parity
1 1 Odd parity
2 2 No parity *
2 0 0 1 stop bit *
4 4 2 stop bits
4,3 0 0 10 bit character length *C0*
8 8 11 bit character length *C1
16 10 9 bit character length *C2
24 18 8 bit character length *C3
7-5 0 0 Profile 0 as active settings after power on. Z0
32 20 Profile 1 as active settings after power on. Z1
64 40 Profile 2 as active settings after power on. Z2
96 60 Profile 3 as active settings after power on Z3
128 80 Factory default as active settings after power on Z4*
S16= dec hex Test status register. +000
0 0 No test in progress. &T0
1 1 Analog Loop-back test in progress. &T1
3 3 Local Digital Loop-back test in process. &T3
6 6 Remote Digital Loop-back test in process. &T6
7 7 Remote Digital Loop-back with self-test in process. &T7
8 8 Analog Loop back with self-test in progress. &T8
S17= bit dec hex Bit-mapped register. +022
4-1 0-30 0-1E Set transmit power level from 0 to -15 dBm. (See also
S35b3) (Default *P11) *Pn
5 0 0 Normal dial. (Default) D
32 20 Reverse dial, go on-line in answer mode. DR
7, 6 0 0 AT Commands set *I0*
64 40 V.25bis command set *I1
128 80 Dumb mode (no command accepted) *I2
S18= dec hex Force modem to fix baud rate when answering. +000
0 0 Disable fixed baud function. *
1-46 1-2E Enable baud rate to be fixed when answering. Baud
rate value settings (n) the same as S20
S19= dec hex +000/&Nn
0-99 0-63
Modem connection mode, same
Setting value as 'AT&Nn' command.
S20= dec hex DTE speed (bps). Auto detected from AT Command. +001
