TABLE 20 – CONDENSER FAN MOTOR RLA
RLA Each Motor
208V/3PH/60HZ
230V/3PH/60HZ
460V/3PH/60HZ
575V/3PH/60HZ
7.3
6.2
3.1
2.5
UNIT SIZE
QUANTITY OF
FANS
208V/3PH/60HZ
230V/3PH/60HZ
460V/3PH/60HZ
575V/3PH/60HZ
50-65 Tons
4
29.2
24.8
12.4
10.0
TABLE 18 – SUPPLY AND EXHAUST FAN MOTOR DATA - ODP
High Effi ciency
Premium Effi ciency
Motor
HP
Nominal Voltage
Motor
HP
Nominal Voltage
208/3/60
230/3/60
460/3/60
575/3/60
208/3/60
230/3/60
460/3/60
575/3/60
FLA
FLA
FLA
FLA
FLA
FLA
FLA
FLA
5
14.0
13.8
6.9
5.3
5
13.8
13.2
6.6
5.2
7.5
21.7
20.0
10.0
8.2
7.5
20.0
19.4
9.7
7.4
10
28.2
26.0
13.0
11.0
10
26.0
25.0
12.5
10.3
15
41.0
38.0
19.0
16.2
15
37.4
35.4
17.7
14.1
20
53.0
48.0
24.0
19.8
20
49.4
47.0
23.5
18.9
25
66.0
62.0
31.0
23.8
25
63.3
60.0
30.0
24.2
30
84.0
72.0
36.0
29.0
30
74.1
70.0
35.0
28.0
40
106.0
98.0
49.0
38.8
40
97.5
92.0
46.0
37.4
TABLE 19 – SUPPLY AND EXHAUST FAN MOTOR DATA - TEFC
High Effi ciency
Premium Effi ciency
Motor
HP
Nominal Voltage
Motor
HP
Nominal Voltage
208/3/60
230/3/60
460/3/60
575/3/60
208/3/60
230/3/60
460/3/60
575/3/60
FLA
FLA
FLA
FLA
FLA
FLA
FLA
FLA
5
15.4
14.2
7.1
5.4
5
13.6
13.0
6.5
5.2
7.5
21.2
19.6
9.8
8.2
7.5
21.0
18.8
9.4
8.0
10
27.5
25.6
12.8
11.4
10
26.0
25.0
12.5
10.0
15
40.0
37.0
18.5
15.3
15
38.9
37.0
18.5
14.8
20
54.0
50.0
25.0
19.1
20
51.0
48.0
24.0
19.0
25
64.0
60.0
30.0
25.0
25
63.3
60.0
30.0
23.9
30
78.0
72.0
36.0
29.6
30
77.0
72.0
36.0
29.0
40
101.0
94.0
47.0
38.0
40
99.0
92.0
46.0
36.8
TABLE 21 – MISCELLANEOUS DATA
Description
Nominal Voltage
208V/230V
460V
575V
AMPS
AMPS
AMPS
Contrl Transformer 0.5 KVA
2.4
1.1
0.9
Convenience Outlet
9.6
4.4
3.5
Gas Heat
9.6
4.4
3.5
