JOHNSON CONTROLS 16
FORM 100.50-EG5 (108)
Physical Data
TABLE 6 – PHYSICAL DATA - COMPRESSORS
Compressors Utilized Compressor Nominal Tons
% Capacity Per Stage
System 1 System 2 System 1 System 2
“Compr
# 1”
“Compr
# 2”
“Compr
# 3”
“Compr
# 4”
“Compr
# 1”
“Compr
# 2”
“Compr
# 3”
“Compr
# 4”
“Stage
1”
“Stage
2”
“Stage
3”
“Stage
4”
Model
050 ZP137 ZP120 ZP137 ZP120 13.58 12.53 13.58 12.53 26.0 52.0 76.0 100.0
051 ZP137 ZP137 ZP137 ZP137 13.58 13.58 13.58 13.58 25.0 50.0 75.0 100.0
060 ZP182 ZP137 ZP182 ZP137 17.95 13.30 17.95 13.30 28.7 57.4 78.7 100.0
061 ZP182 ZP137 ZP182 ZP154 17.95 13.30 17.60 14.86 28.2 55.8 76.7 100.0
TABLE 5 – PHYSICAL DATA – UNIT EER EER
Model
Supply Blower
Type
Cooling Only Gas Heat
YPAL050
Forward-Curved 10.3 10.0
Air Foil 10.3 10.1
YPAL051
Forward-Curved 10.2 9.9
Air Foil 10.2 10.0
YPAL060
Forward-Curved 10.1 9.8
Air Foil 10.1 9.9
YPAL061
Forward-Curved 10.1 9.8
Air Foil 10.1 9.9
TABLE 4 – EFFICIENCY RATINGS CV
IEER
VAV
IEER Model IPLV
YPAL050 10.9 11.3 13.5
YPAL051 10.6 11.2 13.1
YPAL060 10.4 11.0 13.4
YPAL061 10.3 10.8 13.2
