14

Figure 2

shows the AC panel of the XPower 400 Plus and

XPower 700 Plus inverters.

Figure 2 AC Panel of XPower 400 Plus and XPower 700 Plus

AC Outlets

XPower 175 Plus An AC receptacle is located on one end of

the XPower 175 Plus. You can plug in any 120-volt
appliances with a combined total power consumption of 150

watts or less when the inverter is turned on.

3

4

1

2

1
