FORM 100.50-EG1
7
YORK INTERNATIONAL
Physical Data
TABLE 1 – PHYSICAL DATA
MODEL SIZE
50
55
60
65
GENERAL DATA
Length (Inches)
336
336
336
336
Width (Inches)
92
92
92
92
Height (Inches)
82
82
82
82
Operating Weights (Lbs.) (base unit, no options)
Cooling Only (Rigging & Refrigerant)
8,080
8,290
8,530
8,740
Rigging Weights (Lbs.) (base unit, no options)
Cooling Only
8,010
8,210
8,440
8,640
Option Weights (Lbs.)
Power Exhaust (Blower, motor, fan skid & mod damper)
647
647
647
647
Power Exhaust (Blower, motor, fan skid, VFD & baro damper)
654
654
654
654
100% AMS (Measurement Station & Mounting)
110
110
110
110
25/75% AMS (Measurement Station & Mounting)
130
130
130
130
Min. AMS (Measurement Station & Mounting)
40
40
40
40
Barometric only
36
36
36
36
Condenser Hail Guard
32
32
32
32
Copper Condenser Coils
617
617
793
793
Copper Evaporator Coils
262
320
400
500
Roof Curb Weights (Lbs.)
14" Full Perimeter Roof Curb
787
787
787
787
14" Open Condenser Roof Curb
555
555
555
555
Compressor Data
Quantity / Size (Nominal Tons )
4/13
4/13
4/15
4/15
Type
Scroll
Scroll
Scroll
Scroll
Capacity Steps (%)
25, 50, 75, 100
25, 50, 75, 100
25, 50, 75, 100
25, 50, 75, 100
Supply Fan and Drive
Quantity
1
1
1
1
Type
FC
FC
FC
FC
Size
25-22
25-22
25-22
25-22
Motor Size Range (min. to max. HP)
7.5-40
7.5-40
7.5-40
7.5-40
Air Flow Range (min. to max. cfm)
10000-22500
12000-24000
14000-27000
14000-27000
Static Pressure Range (min. to max. ESP)
0-4"
0-4"
0-4"
0-4"
Exhaust Fan
Quantity
2
2
2
2
Type
FC
FC
FC
FC
Size
15-15
15-15
15-15
15-15
Motor Size Range (min. to max. HP)
5-20
5-20
5-20
5-20
Air Flow Range (min. to max. cfm)
0-20000
0-20000
0-20000
0-20000
Static Pressure Range (min. to max. ESP)
0-1"
0-1"
0-1"
0-1"
Evaporator Coil
Size (square feet)
48.8
48.8
48.8
48.8
Number of rows/fins per inch
3/8
4/8
4/12
5/10
Tube Diameter/Surface
1/2"/enhanced
1/2"/enhanced
1/2"/enhanced
1/2"/enhanced
Condenser Coil (Aluminum Fins)
Size (square feet)
121.3
121.3
121.3
121.3
Number of rows/fins per inch
3/14
3/14
3/18
3/18
Tube Diameter
3/8"
3/8"
3/8"
3/8"
Condenser Coil (Copper Fins – Opt)
Size (square feet)
121.3
121.3
121.3
121.3
Number of rows/fins per inch
3/14
3/14
3/18
3/18
Tube Diameter
3/8"
3/8"
3/8"
3/8"
