The ML605 supports Master BPI-Up, JTAG, and Slave SelectMAP. These are selected by
setting M[2:0] options 010, 101 and 110 shown in
For an overview on configuring the FPGA, see
Configuration Options, page 76
.
Note:
The mode switches are part of DIP switch S2. The default mode setting (see
) is M[2:0]=010, which selects Master BPI-Up at board power-on. Switch S1 position 4 must
be OFF to disable the System ACE controller from attempting to boot if a CF card is present.
References
See the Virtex-6 FPGA Configuration User Guide for detailed configuration information.
I/O Voltage Rails
There are 16 I/O banks available on the Virtex-6 device. The voltage applied to the FPGA
I/O banks used by the ML605 board is summarized in
Table 1-2:
Virtex-6 FPGA Configuration Modes
Configuration Mode
M[2:0]
Bus Width
(1)
CCLK Direction
Master Serial
(2)
000
1
Output
Master SPI
(2)
001
1
Output
Master BPI-Up
(2)
010
8, 16
Output
Master BPI-Down
(2)
011
8, 16
Output
Master SelectMAP
(2)
100
8, 16
Output
JTAG
101
1
Input (TCK)
Slave SelectMAP
110
8, 16, 32
Input
Slave Serial
(3)
111
1
Input
Notes:
1. The parallel configuration modes bus is auto-detected by the configuration logic.
2. In Master configuration mode, the CCLK pin is the clock source for the Virtex-6 FPGA internal
configuration logic. The Virtex-6 FPGA CCLK output pin must be free from reflections to avoid
double-clocking the internal configuration logic. See the Virtex-6 FPGA Configuration User Guide for
more details.
3. This is the default setting due to internal pull-up termination on mode pins.
Table 1-3:
Voltage Rails
U1 FPGA Bank
I/O Rail
Voltage
Bank 0
VCC2V5_FPGA
2.5V
Bank 12
(1)
FMC_VIO_B_M2C
2.5V
Bank 13
VCC2V5_FPGA
2.5V
Bank 14
VCC2V5_FPGA
2.5V
Bank 15
VCC2V5_FPGA
2.5V
Bank 16
VCC2V5_FPGA
2.5V
Bank 22
VCC2V5_FPGA
2.5V
Bank 23
VCC2V5_FPGA
2.5V
