Page 77
3-07
565 Trailer Sprayer - Parts & Schematics
Section F
Description:
Vertical Mast Cylinder
24
Section F
1
TA-02053
Tube Assembly
1
2
RA-01163
Rod
1
3
PI-00002
Piston
1
4
HE-00040
Head
1
5
PP-00014
Locknut, 3/4-16
1
6
MM-00036
Retaining Ring
1
7*
O-Ring
1
8*
O-Ring
1
9*
Back-up
2
10*
O-Ring
1
11*
Back-up
1
12*
O-Ring
1
13*
Back-up
1
14*
Wiper
1
SK-00924
Seal Kit
Item#
Part #
Description
Quantity
* Not Sold Separately, Only Available as a Seal Kit.
