3-07
565 Trailer Sprayer - Parts & Schematics
Section F
Description: Center Boom Assembly
14
Section F
1 014855 Weldment; Boom Center 1
2 014871 Weldment; Pin 10.125 w/Threads 2
3 014937 Slide; UHMW .625 x 1.75 x 11.00 w/HOLS 4
4 014947 Weldment; Wing Tilt Adj Rod 2
5 014951 Round, CR; .625 x 2.625 w/HOLS 2
6 015812 Screw, Torx; 1/4-20 x 1.00 12
7 FW-087 Flatwasher; 7/8” 4
8 LN-075-NI Locknut; 3/4” Nylon Insert 2
9 MB-062-100-14 Bushing, Machine 5/8 x 1.00 4
10 NUT-087 Nut; 7/8” Nut 4
11 PCT-015-150 Pin; Cotter, 5/32 x 1 1/2 11
Item# Part # Description Quantity
