3-07
565 Trailer Sprayer - Parts & Schematics
Section F
Description: 565 Tank & Sprayer Front Assembly
Tank/Handrail/Ladder
6 AC217944 Weldment; Ladder Mount 1
7* 016062 Weldment; Cradle 565 1
8 AC313519 Weldment; Ladder 1
9 AC607449 Jack; Swivel, Side Wind, 2000# 1
10 AC607451 Snap Ring; Part of AC607449 1
11 NW60012 Rim for 16” Lid 1
12 SFPI-10ST Screw; 1”x #10 FH PH Self Tap, SS 8
13 0254-1035 Rope; 1/8” Nylon
14 NW60011 Lid; 16” with Air Vent 1
15 BT-038-500-2 Bolt; Tap, 3/8” x 5” Hex. GR.2 12
16 FW-038 Flat Washer; 3/8” 36
17 NUT-038 Nut; 3/8” 28
18 PLI-038-250 Pin; Linch Pin; 3/8” x 2 1/2” 1
19 BH-075-600-5 Bolt; 3/4” x 6” Hex. GR. 5 1
20 FW-075 Flat Washer; 3/4” 2
21 LN-075-CL Lock Nut; 3/4” Center Lock 1
22 BH-038-125-5 Bolt; 3/8” x 1 1/4” Hex. GR. 5 8
23 LN-038-NI Lock Nut; 3/8” Nylon Insert 16
24 BH-038-100-5 Bolt; 3/8” x 1” Hex. GR. 5 8
25 BU031-150-250-2 U-Bolt; 5/16” x 1 1/2” x 2 1/2” 4
26 014159 Manual Bracket, Bent 1
27 013049 Tube; Manual Storage 1
28 NW60401 Bulkhead Fitting; 3/4” 2
29 HB-075-90 Hose Barb ELL; 3/4MPT x HB Poly 2
30 SIGHT-34 Hose; 3/4 I.D. x 1/8 Sight Hose
31 #12J Clamp; 3/4” x 1/2” Stainless 2
32* 007679 Weldment; Pigtail 1
33 BH-031-100-2 Bolt; 5/16” x 1” Hex. GR. 2 2
34 LN-031-NI Lock Nut; 5/16” Nylon Insert 10
35 NW60019 Air Vent Assembly 1
36 NW60038 16” Lid, Ring, & Fill Cap 1
37 #64J Clamp; 4” x 1/2” Stainless 2
38 171-C Screw; TEK 410HSS CAD Plated 8
39 016059 Plastic; Vertical Boom Pad 2
40 016180 Plastic; Cradle Horizontal 2
Item# Part # Description Quantity
8
Section F
* Specify Color
