Redball Electrical 565 - Manual (Page 65)

3-07
565 Trailer Sprayer - Parts & Schematics
Section F
12
Section F
Description: 60 Ft. Boom Carriage & Suspension
1 014896 Weldment; Boom Carriage 1
2 014906 Bushing; 1.06 OD Stepped x .650 ID 2
3 014908 Flat; .375 x 2.00 x 5.25 w/holes 4
4 014911 Spring; 5.25 OD x 12.75 Lg, .56 Wire 2
5 014919 Washer, Belleville; 7/8 ID x 1 3/4 OD 14 Ga. 16
6 014921 Weldment; Linkage, Suspension 2
7 014929 Weldment; Stabilizer Arm LH W/Mount 1
8 014930 Weldment; Stabilizer Arm RH 1
9 014931 Rubber; 2.375 OD x 2.438 Lg W/ CRSHOL 1
10 014935 Assembly; Cable 54” 2
11 014938 Shock Absorber; 10.73 Closed 17.11 Open 2
12 014939 Threaded Rod; 5/8-11 w/Flat & Hole 2
13 014941 Weldment; .875 Pin w/Threads 2
14 014943 Weldment; .875 Pin w/Formed Tab 5
15 014952 Channel; 3” 4.1# x 32.75 2
16 014964 Urethane, Bumper; 2.00 x 1.60 w/3/8 Thread 2
17 015772 Slide; UHMW .438 x 1.75 x 11.00 w/HOLS 4
18 015810 Clevis, Screw; 3/8” 2
19 015887 Plug, Plastic; 2 1/2” 2
20 016253 Urethane, Bumper; 95A 2.00 x 1.60 w/Thread 1
21 016273 Tube, Rd; 7/8 x 12 Ga. x 2.88 2
22 BH-038-400-5 Bolt; 3/8 x 4 Grade 5 1
23* BH-062-350-5 Bolt, Hex, 5/8 x 3 1/2 Gr. 5 8
24 BH-062-400-5 Bolt, Hex, 5/8 x 4 Gr. 5 4
25 BM-025-100-CS Screw, 1/4-20 x 1.00 12
26 G1641 Zerk; Grease; 1/4” - 28 Straight 9
27 LN-025-NI Locknut; 1/4” Nylon Insert 12
28 LN-038-NI Locknut; 3/8” Nylon Insert 4
29 LN-062-NI Locknut; 5/8” Nylon Insert 19
30 NUT-062 Nut; 5/8” Nut 4
Item# Part # Description Quantity
* Not Shown
