035-19046-002-B-0104
22 Unitary Products Group
OPTIONAL ELECTRIC HEAT
The factory-installed heaters are wired for single point power
supply. Power supply need only be brought into the single
point terminal block.
These CSA approved heaters are located within the central
compartment of the unit with the heater elements extending
into the supply air chamber.
Fuses are supplied, where required, by the factory. Some kW
sizes require fuses and other do not. Refer to Table 11 for
minimum CFM limitations and to Tables 8 through 9 for elec-
trical data.
TABLE 10: PHYSICAL DATA
Component
Model
DJ150
Evaporator
Blower
Blower, Centrifugal (Dia. X Wd. in.) 15 x 15
Motor, Standard (HP) 3
Motor, Optional (HP) 5
Evaporator
Coil
Rows 4
Fins per Inch 15
Height (in.) 40
Face Area (ft.
2
each) 13.2
Condenser
Fan
(4 per Unit)
Propeller Dia. (in., each) 24
Motor (HP, each) 1/3
CFM, Nominal (each) 3000
Condenser
Coil
(2 per unit)
Rows (each) 2
Fins per Inch 20
Height (in. each) 44
Face Area (ft.
2
each) 14.5
Refrigerant
Charge
System 1 (lb./oz.) 11/0
System 2 (lb./oz.) 11/8
Compressors
Quantity 2
Type Scroll
Air Filters
Size (Wd. x Ht. x Thickness in.) 25x20x2
Number Per Unit 4
TABLE 11: MINIMUM SUPPLY AIR CFM
Heater Unit Model Size, Nominal Tons
kW Voltage
12.5
Minimum Supply Air CFM
18
208/230 3750
24
36
54
18
480 3750
24
36
54
18
600 3750
24
36
54
