When these match units are enabled, all slaves or masters are enabled. You cannot individually enable a particular
master.
The match units 7, 8, and 9 are slave side signals for BUSY, READ, and WRITE error controls going to the mas-
ter. These units are broken out individually because this bus has one signal for each master on each slave. Conse-
quently, you can have up to 256 signals on each one of these match units (if PLB goes to a 16 slave, 16 master
solution).
The arbiter status signals can be monitored using match unit 10. The signals probed by this match unit can help
identify the order of the PLB master transactions that are being sorted on the bus.
ChipScope PLB46 IBA Parameters
To create a ChipScope PLB46 IBA uniquely tailored for your system and to optimize performance, specific fea-
tures can be parameterized on the PLB IBA.
Table 2 describes the features that can be parameterized.
The ChipScope PLB IBA peripheral supports multiple trigger units that connect to the PLB Control bus, Address
bus, Data bus, lumped Slave or Master busses. Each one of these trigger units can be enabled and parameterized
independently.
Table 2 lists all the parameters used in selecting the trigger port connections. These parameters
define what signals are connected to the trigger ports, the match unit type, and if the signals are stored in the sam-
ple buffer.
Table 2: IBA_PLBv46 Design Parameters
Generic Feature/Description Parameter Name
Allowable
Values
Default
Value
VHDL
Type
G1 Target Family C_FAMILY spartan3,
spartan3e,
spartan3a,
spartan3adsp,
spartan3an,
virtex4, virtex5
virtex5 String
G2 Device C_DEVICE String
G3 Device Package C_PACKAGE String
G4 Device speed grade C_SPEEDGRADE String
G5 Number of PLB Masters C_PLBV46_NUM_MASTERS 1-8 2 Integer
G6 Number of PLB Slaves C_PLBV46_NUM_SLAVES 1-8 1 Integer
G7 Number of bits required to encode
the number of PLB Masters C_PLBV46_MID_WIDTH 1-5 2 Integer
G8 PLB Address Bus Width C_PLBV46_AWIDTH 32 32 Integer
G9 PLB Data Bus Width C_PLBV46_DWIDTH 32,64,128 64 Integer
IBA Storage Options and Trig Out
G10 Number of data samples captured for
every trigger match. Note that the
range of acceptable values depends
on the C_FAMILY value.
C_NUM_DATA_SAMPLES 512, 1024, 2048,
4096, 8192,
16384, 32768,
65536, 131072
1024 Integer
G11 Number of sequencer levels. If 0
then no sequencer is used. C_MAX_SEQUENCER_
LEVELS 0-16 2 Integer
G12 1=Enable data store qualification
(filtering)
0=Disable
C_ENABLE_STORAGE_
QUALIFICATION
0,1 1 Integer
