P2302R-P1C Support Notes


All contents Copyright

2007 ZyXEL Communications Corporation.

144

TCP Data: (Length=1127, Captured=42)

0000: DF 33 AF 62 58 37 52 3D-79 99 A5 3C 2B 59 E2 78 .3.bX7R=y..<+Y.x

0010: A7 98 8F 3F A9 09 E4 0F-26 14 9C 58 3E 95 3E E7 ...?....&..X>.>.

0020: FC 2A 4C 2F FB BE 2F FE-EF D0 .*L/../...

RAW DATA:

0000: 00 A0 C5 92 13 12 00 A0-C5 01 23 45 08 00 45 00 ..........#E..E.

0010: 04 8B B1 39 40 00 EE 06-A9 AB C0 1F 07 82 CA 84 ...9@...........

0020: 9B 61 00 50 28 1E D3 E9-59 85 00 C1 8F 63 50 19 .a.P(...Y....cP.

0030: FA F0 37 35 00 00 DF 33-AF 62 58 37 52 3D 79 99 ..75...3.bX7R=y.

0040: A5 3C 2B 59 E2 78 A7 98-8F 3F A9 09 E4 0F 26 14 .<+Y.x...?....&.

0050: 9C 58 3E 95 3E E7 FC 2A-4C 2F FB BE 2F FE EF D0 .X>.>..*L/../...

Offline Trace

1. Trace LAN packet
2. Trace WAN packet

1. Trace LAN packet

1.1 Disable the capture of the WAN packet by entering:

sys trcp channel mpoa00 none

1.2 Enable the capture of the LAN packet by entering:

sys trcp channel enet0 bothway

1.3 Enable the trace log by entering:

sys trcp sw on

&

sys trcl sw on

1.4 Wait for packet passing through the ZyXEL Device over LAN

1.5 Disable the trace log by entering:

sys trcp sw off

&

sys trcl sw off

1.6 Display the trace briefly by entering:

sys trcp brief

1.7 Display specific packets by using:

sys trcp parse

2. Trace WAN packet

1.1 Disable the capture of the LAN packet by entering:

sys trcp channel enet0 none

1.2 Enable the capture of the WAN packet by entering:

sys trcp channel mpoa00 bothway

1.3 Enable the trace log by entering:

sys trcp sw on

&

sys trcl sw on

1.4 Wait for packet passing through the ZyXEL Device over WAN

1.5 Disable the trace log by entering:

sys trcp sw off

&

sys trcl sw off
