P2302R-P1C Support Notes


All contents Copyright

2007 ZyXEL Communications Corporation.

129

1. Trace LAN packet

1.1 Disable to capture the WAN packet by entering:

sys trcp channel enet1 none

1.2 Enable to capture the LAN packet by entering:

sys trcp channel enet0 bothway

1.3 Enable the trace log by entering:

sys trcp sw on

&

sys trcl sw on

1.4 Wait for packet passing through the ZyXEL Device over LAN
1.5 Disable the trace log by entering:

sys trcp sw off

&

sys trcl sw off

1.6 Display the trace briefly by entering:

sys trcp brief

1.7 Display specific packets by using:

sys trcp parse

Exmaple:

Prestige> sys trcp channel enet1 none

Prestige> sys trcp channel enet0 bothway

Prestige> sys trcp sw on

Prestige> sys trcl sw on

Prestige> sys trcp sw off

Prestige> sys trcl sw off

Prestige> sys trcp brief

0 10855.790 ENET0-T[0141] TCP 192.31.7.130:80->192.168.1.2:1102

1 10855.800 ENET0-R[0060] TCP 192.168.1.2:1102->192.31.7.130:80

2 10855.810 ENET0-R[0062] TCP 192.168.1.2:1103->192.31.7.130:80

3 10855.840 ENET0-R[0062] TCP 192.168.1.2:1104->192.31.7.130:80

4 10856.020 ENET0-T[0054] TCP 192.31.7.130:80->192.168.1.2:1102

5 10856.030 ENET0-T[0058] TCP 192.31.7.130:80->192.168.1.2:1103

6 10856.040 ENET0-R[0060] TCP 192.168.1.2:1103->192.31.7.130:80

Prestige> sys trcp parse 5 5

---<0005>----------------------------------------------------------------

LAN Frame: ENET0-XMIT Size: 58/ 58 Time: 10856.030 sec

Frame Type: TCP 192.31.7.130:80->192.168.1.2:1103

Ethernet Header:
