P2302R-P1C Support Notes


All contents Copyright

2007 ZyXEL Communications Corporation.

125

or
1.5 Display the detailed trace online by entering:

sys trcd parse

Example:

Prestige> sys trcp channel enet0 none

Prestige> sys trcp channel enet1 bothway

Prestige> sys trcp sw on

Prestige> sys trcl sw on

Prestige> sys trcd brief

0 12367.680 ENET1-R[0070] UDP 202.132.155.95:520->202.132.155.255:520

1 12370.980 ENET1-T[0062] TCP 202.132.155.97:10261->192.31.7.130:80

2 12373.940 ENET1-T[0062] TCP 202.132.155.97:10261->192.31.7.130:80

3 12374.930 ENET1-R[0064] TCP 192.31.7.130:80->202.132.155.97:10261

4 12374.940 ENET1-T[0054] TCP 202.132.155.97:10261->192.31.7.130:80

5 12374.940 ENET1-T[0438] TCP 202.132.155.97:10261->192.31.7.130:80

6 12375.320 ENET1-R[0064] TCP 192.31.7.130:80->202.132.155.97:10261

7 12375.360 ENET1-R[0090] UDP 202.132.155.95:520->202.132.155.255:520

Prestige> sys trcd parse

---<0000>----------------------------------------------------------------

LAN Frame: ENET1-RECV Size:1181/ 96 Time: 12387.260 sec

Frame Type: TCP 192.31.7.130:80->202.132.155.97:10270

Ethernet Header:

Destination MAC Addr = 00A0C5921312

Source MAC Addr = 00A0C5012345

Network Type = 0x0800 (TCP/IP)

IP Header:

IP Version = 4

Header Length = 20

Type of Service = 0x00 (0)

Total Length = 0x048B (1163)

Idetification = 0xB139 (45369)

Flags = 0x02

Fragment Offset = 0x00

Time to Live = 0xEE (238)
