P2302R-P1C Support Notes


All contents Copyright

2007 ZyXEL Communications Corporation.

138

0 11880.160 ENET0-R[0062] TCP 192.168.1.2:1108->192.31.7.130:80

[index] [timer/second][channel-receive/transmit][length] [protocol] [sourceIP/port] [destIP/port]

There are two ways to dump the trace:

1. Online Trace--display the trace real time on screen

2. Offline Trace--capture the trace first and display later

The details for capturing the trace in SMT menu 24.8 are as follows.

Online Trace

1. Trace LAN packet
2. Trace WAN packet

1. Trace LAN packet

1.1 Disable to capture the WAN packet by entering:

sys trcp channel mpoa00 none

1.2 Enable to capture the LAN packet by entering:

sys trcp channel enet0 bothway

1.3 Enable the trace log by entering:

sys trcp sw on

&

sys trcl sw on

1.4 Display the brief trace online by entering:

sys trcd brief

or
1.5 Display the detailed trace online by entering:

sys trcd parse

Example:

ras> sys trcp channel mpoa00 none

ras> sys trcp channel enet0 bothway

ras> sys trcp sw on

ras> sys trcl sw on

ras> sys trcd brief

0 11880.160 ENET0-R[0062] TCP 192.168.1.2:1108->192.31.7.130:80

1 11883.100 ENET0-R[0062] TCP 192.168.1.2:1108->192.31.7.130:80

2 11883.330 ENET0-T[0058] TCP 192.31.7.130:80->192.168.1.2:1108

3 11883.340 ENET0-R[0060] TCP 192.168.1.2:1108->192.31.7.130:80
