Prestige 2002 Series
5
LABEL DESCRIPTION
1. PC Connect a computer to this port with an Ethernet cable. This port is auto-negotiating (can
connect at 10 or 100Mbps) and auto-sensing (automatically adjusts to straight-through or
crossover Ethernet cable).
2. LAN Connect a cable/DSL modem or router or an Ethernet LAN switch to this port with the
Ethernet cable that came with your modem.
3. PHONE 1-2 Connect analog telephones to these ports using telephone wire. These are FXS (Foreign
Exchange Station) ports.
4. POWER Use the included power adaptor to connect the POWER socket to an appropriate power
source (see the User’s Guide for power adaptors by region).
The PWR/VoIP LED turns on. The LAN, PC and Phone 1 and 2 LEDs turn on if the LAN, PC and PHONE
ports are properly connected.
RESET You only need to use this button if you’ve forgotten the Prestige’s password. It returns the
Prestige to the factory defaults (password is 1234, management IP address 192.168.5.1
etc.; see your User’s Guide for details).
2.3 Prestige 2002L
The Prestige 2002L’s lifeline feature adds regular phone services. Make and receive regular phone
calls while someone else connected to the Prestige is making VoIP calls.
Use the Prestige 2002L’s included gray telephone wire to connect the LINE port to the telephone
jack. The LINE port is a FXO (Foreign Exchange Office) port.
