Maintenance
34 Xerox DP 820 User’s Guide
Preset Signals
The following tables describe the projector’s preset signals.
Preset Signal fH (kHz) fV (Hz) Sync Size
640 X 480 VGA MODE 3 31.469 59.940 H(-), V(-) 800
VGA VESA 72 H Z 37.861 72.809 H(-), V(-) 832
VGA VESA 75 H Z 37.500 75.500 H(-), V(-) 840
VGA VESA 85 H Z 43.269 85.008 H(-), V(-) 832
800 X 600 SVGA VESA 56 H Z 35.156 56.250 H(+), V(+) 1024
SVGA VESA 60 H Z 37.879 60.317 H(+), V(+) 1056
SVGA VESA 72 H Z 48.077 72.188 H(+), V(+) 1040
SVGA VESA 75 H Z 46.875 75.000 H(+), V(+) 1056
SVGA VESA 85 H Z 53.674 85.061 H(+), V(+) 1048
1024 X 768 XGA VESA 60 H Z 48.363 60.004 H(+), V(-) 1344
XGA VESA 70 H Z 56.476 70.069 H(+), V(-) 1328
XGA VESA 75 H Z 60.023 75.029 H(+), V(+) 1312
XGA VESA 85 H Z 68.677 84.997 H(+), V(+) 1376
1152 X 864 SXGA VESA 70 H Z 63.995 70.016 H(+), V(+) 1472
SXGA VESA 75 H Z 67.500 75.000 H(+), V(+) 1600
SXGA VESA 85 H Z 77.487 85.057 H(+), V(+) 1568
1280 X 960 SXGA VESA 60 H Z 60.000 60.000 H(+), V(+) 1800
SXGA VESA 75 H Z 75.000 75.000 H(+), V(+) 1680
1280 X 1024 SXGA VESA 60 H Z 63.981 60.020 H(+), V(+) 1688
