COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils
UNIT MODEL
FURNACE**
COIL
MODEL
COOLING
CFM RANGE
(Min.-max.)
W
RATED
CFM
NET MBH
SEER
1
EER
TOTAL
SENS.
YCJF24S41S1
600 - 1000
14,17
FC/MC/PC24
800
24.8
17.3
14.00
12.00
600 - 1000
14,17
FC/MC/PC30
800
24.8
17.3
14.00
12.00
600 - 1000
14
FC/MC/PC32
800
25
17.6
14.50
12.35
600 - 1000
17,21
FC/MC/PC35
800
25
17.6
14.50
12.35
600 - 1000
14,17,21
FC/MC/PC36
800
25
17.6
14.00
12.00
600 - 1000
14
FC/MC/PC37
800
25.4
17.9
14.50
12.35
600
-
1000 17,21
FC/MC/PC43
800 25.2 18 14.70
12.50
600 - 1000
21
FC/MC/PC48
800
25.6
18.3
14.80
12.65
600 - 1000
14
HC18
800
24.2
16.7
14.00
12.00
600 - 1000
14
HC30
800
24.8
17.4
14.00
12.00
600 - 1000
17
HC36
800
25
17.6
14.00
12.00
600
-
1000
21 HC42 800 25.4 18 14.50
12.35
600 - 1000
14,17
HD24
800
25.4
17.7
14.50
12.35
600
-
1000 14,17,21
HD36 800 24.8 17 14.00
12.00
600 - 1000
21
HD48
800
25.6
17.9
14.50
12.35
600 - 1000
14,17
UC24
800
25
17.5
14.00
12.00
600 - 1000
14,17
UC30
800
25
17.5
14.00
12.00
YCJF30S41S1
800 - 1200
14,17
FC/MC/PC30
1000
28.8
20.6
14.00
12.00
800 - 1200
14,17
FC/MC/PC32
1000
29
21
14.00
12.00
800 - 1200
17,21
FC/MC/PC35
1000
29
21
14.00
12.00
800 - 1200
14,17,21
FC/MC/PC36
1000
29
21
14.00
12.00
800 - 1200
14
FC/MC/PC37
1000
29.6
21.6
14.50
12.35
800 - 1200
17,21
FC/MC/PC43
1000
29.6
21.6
14.50
12.35
800 - 1200
21,24
FC/MC/PC48
1000
30
21.8
14.50
12.35
800 - 1200
17
HC36
1000
29
21
14.00
12.00
800 - 1200
21
HC42
1000
29.6
21.6
14.25
12.10
800 - 1200
14,17,21
HD36
1000
28.8
20.2
14.00
12.00
800 - 1200
21,24
HD48
1000
29.8
21.4
14.50
12.35
800 - 1200
14,17
UC30
1000
29
20.8
14.00
12.00
YCJF36S41S1
1000 - 1400
17,21
FC/MC/PC35
1200
33.6
24.6
14.00
11.90
1000 - 1400
14,17,21
FC/MC/PC36
1200
33.4
24.2
14.00
11.85
1000 - 1400
14
FC/MC/PC37
1200
34.4
25.2
14.50
12.20
1000 - 1400
17,21
FC/MC/PC43
1200
34.4
25.2
14.50
12.20
1000 - 1400
21,24
FC/MC/PC48
1200
34.6
25.4
14.50
12.25
1000 - 1400
17
HC36
1200
33.6
24.6
14.00
11.90
1000 - 1400
21
HC42
1200
34.4
25.2
14.50
12.20
1000 - 1400
14,17,21,24
HD48
1200
34.6
25
14.50
12.20
1000 - 1400
21,24
UC60
1200
33.2
23.8
14.00
11.75
YCJF42S41S1
1200
-
1600
17,21
FC/MC/PC43
1400.00
40.50 30.40 14.00 12.00
1200
-
1600
21,24
FC/MC/PC48
1400.00
41.00 30.80 14.50 12.30
1200
-
1600
21,24
FC/MC/PC60
1400.00
41.00 30.80 14.50 12.30
1200
-
1600
21
HC42 1400.00
40.50 30.40 14.00 12.00
1200
-
1600 14,17,21,24
HD48 1400.00
41.00 30.40 14.25 12.10
1200
-
1600
21,24 HD60 1400.00
41.50 31.20 14.50 12.30
1200
-
1600
21,24 FC/MC62
1400.00
41.00 31.00 14.50 12.30
YCJF48S41S1
1400
-
1800
21,24
FC/MC/PC48
1600.00
46.50 32.80 14.25 12.10
1400
-
1800
21,24
FC/MC/PC60
1600.00
46.50 32.60 14.50 12.35
1400
-
1800 14,17,21,24
HD48 1600.00
46.50 32.60 14.50 12.35
1400
-
1800 14,17,21,24
HD60 1600.00
47.50 33.20 14.50 12.35
1400
-
1800
21,24 FC/MC62
1600.00
47.00 32.80 14.50 12.35
YCJF60S41S1
1600 - 2000
21,24
FC/MC/PC60
1800.00
54.50
38.50
13.80
11.90
1600 - 2000
24
HC60
1800.00
54.50
38.50
13.50
11.65
1600
-
2000
21,24 FC/MC62
1800.00
57.00 39.00 14.00 12.10
1. Requires a 2FD06700224 Blower Time Delay unless a standard furnace is equipped with one.
** Refer to Quick Selection Chart for specific furnace match-up.
