2 Preparing To Print
20 8254E / 8264E Quick Start Guide
2.5 8254E Setting roll media
Follow the procedure below to set the roll media on the 8254E.
1. Press the [Power] key to turn the unit ON.
• The Power lamp on the control panel lights up in green.
• The printer starts the initializing operation.
• "Media End" is displayed in the control panel.
• Do not operate the media loading lever during initial operation. The print head
portion may touch the pressurizing roller portion, and cause a malfunction.
2. Push the media loading lever toward the rear. "Lever Up" displays in the control panel.
No. Name
1 Media loading lever
