2 Preparing To Print
14 8254E / 8264E Quick Start Guide
6. Eliminate any slack or slant by holding or taping the front edge of the media and rewinding the roll
media a little using the flange on the roll media holder.
• If you don’t hold the front edge of the media while rewinding, it will fall out from
the media feed slot on the rear of the printer.
• Confirm that the right edge of the roll media does not extend outward of the
loading mark on the right side of the media guide at the front of the printer. If it
does, it may negatively affect print quality.
• When setting the roll media, set both sides of the media at least 5mm away from
the edge of the pressurizing roller. If you don’t do this, slippage or creasing may
occur during printing.
No. Name
1 Roll media
2 Media loading mark
