1. G4FD coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. Single phase units require single phase 2HK heaters.
COOLING CAPACITY - With Air Handler Coils
UNIT MODEL
AIR HANDLER
COIL MODEL
1
COOLING
MODEL
ELECTRIC
2
HEAT KW
W
RATED
CFM
NET MBH
SEER
EER
TOTAL
SENS.
1 PH 13 SEER AC WITH MV - VARIABLE SPEED
AY018MA321
MV12B
5,8,10
17
FC/MC18B
600
18.4
12.8
14.50
12.00
MV12B
5,8,10
17
G4FD024H17T2A
600
18.4
12.8
14.50
12.00
AY024MA321
MV12B
5,8,10
17
FC/MC24B
800
24.0
17.7
14.50
12.00
MV12B
5,8,10
17
FC/MC30B
800
24.0
17.7
14.50
12.00
MV12B
5,8,10
17
FC/MC36B
800
24.0
17.7
14.50
12.00
MV12B
5,8,10
17
G4FD030H17T2A
800
24.0
17.7
14.50
12.00
MV12B
5,8,10
17
G4FD036H17T2A
800
24.0
17.7
14.50
12.00
MV16C
5,8,10,15,18,20
21
FC/MC36C
800
24.0
17.7
14.50
12.00
AY030MA321
MV12B
5,8,10
17
FC/MC36B
1000
29.2
21.4
11.70
10.40
MV12B
5,8,10
17
FC/MC42B
1000
29.4
21.6
12.00
10.40
MV12B
5,8,10
17
G4FD036H17T2A
1000
29.2
21.4
11.70
10.40
MV12B
5,8,10
17
G4FD046H17T2A
1000
29.4
21.6
12.00
10.40
MV16C
5,8,10,15,18,20
21
FC/MC36C
1000
29.4
21.6
11.70
10.40
MV16C
5,8,10,15,18,20
21
FC/MC42C
1000
29.4
21.6
11.70
10.40
MV16C
5,8,10,15,18,20
21
G4FD036H21T2A
1000
29.4
21.6
11.70
10.40
MV16C
5,8,10,15,18,20
21
G4FD042H21T2A
1000
29.4
21.6
11.70
10.40
AY036MA321
MV12B
5,8,10
17
FC/MC42B
1200
35.8
25.9
13.75
11.00
MV12B
5,8,10
17
G4FD046H17T2A
1200
35.8
25.9
13.75
11.00
MV16C
5,8,10,15,18,20
21
FC/MC42C
1200
36.0
26.1
14.00
11.50
MV16C
5,8,10,15,18,20
21
FC/MC48C
1200
36.0
26.1
14.00
11.50
MV16C
5,8,10,15,18,20
21
G4FD042H21T2A
1200
36.0
26.1
14.00
11.50
MV16C
5,8,10,15,18,20
21
G4FD048H21T2A
1200
36.0
26.1
14.00
11.50
MV20D
8,10,15,18,20,25
24
FC/MC48D
1200
36.0
26.1
14.00
11.50
MV20D
8,10,15,18,20,25
24
G4FD048H24T2A
1200
36.0
26.1
14.00
11.50
1 PH 13 SEER AC WITH AHP
AY012MA321
AHP18
2,5,8
17
—
430
15.5
9.9
13.50
11.00
AY018MA321
AHP18
2,5,8
17
—
650
18.0
12.4
13.00
11.00
AHP24
2,5,8,10
17
—
655
18.0
12.4
13.00
11.00
AY024MA321
AHP24
2,5,8,10
17
—
830
23.4
17.1
13.00
11.00
AY030MA321
AHP36
5,8,10,15,18
17
—
1040
28.8
21.0
10.90
9.90
AY036MA321
AHP42
5,8,10,15,18
21
—
1255
35.4
25.5
13.00
11.00
1 PH 13 SEER AC WITH F4FP
AY018MA321
F4FP024H06T2A
5,8,10
17
—
600
18.0
12.4
13.00
11.00
AY024MA321
F4FP030H06T2A
5,8,10,15
17
—
800
23.4
17.1
13.00
11.00
AY036MA321
F4FP042H06T2A
5,8,10,15
24
—
1200
35.4
25.5
13.00
11.00
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.
Cooling MBH based on 80ºF entering air temperature, 50% RH, and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at 95ºF outdoor ambient divided by the total electric power in watt-hours at those conditions
.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BUT’s during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
