Xerox DocuColor 4 Copier/Printer 701P31130 - Manual (Page 3)

Getting to Know Your Product
Product Orientation Guide iii
Contents
Carrier session overview 1
What to expect from the Carrier session 1
Component parts of the DocuColor 4 Copier/Printer 2
Component overview 2
Location of the power switches 3
Location of the serial number plate 3
The printer control panel 4
The Scanner/ADF control panel 5
Performing routine tasks 6
Loading paper in the paper trays 6
Loading paper in the bypass tray 7
Making copies using the Automatic Document Feeder 8
Making a copy from the document glass 8
Copy Output 9
Access areas for jam clearance 9
Clearing a jam in the scanner/ADF 9
Clearing a jam in a paper tray 10
Clearing a jam in the bypass tray 11
Clearing a jam in the right side 11
Clearing a jam in the fuser 12
Clearing a jam in the left side 14
Clearing a jam in the two tray module 14
