Getting to Know Your Product
Product Orientation Guide 13
WARNING: Do not touch the white roller
on the oil roll cartridge. The oil will stick
to your skin.
3. Place two pieces of paper on a flat surface to set
the oil roll cartridge on when you remove it.
4. See Figure 25. Remove the oil roll cartridge and
set it aside.
5. Removed the jammed paper in the direction of
the arrow. Be sure no torn pieces of paper are
left inside the fuser area.
6. See Figure 26. Reinsert the oil roll cartridge.
7. Push the lower left unit firmly back into the printer.
!
4
5
Figure 25
6
7
Figure 26
