[ MultiTrack Rhythm Machine ] Date :1999.01.14
Model RhythmTrak RT-123 MIDI Implementation Chart Version :1.00
+---------------------+--------------------+--------------------+---------------------+
| | Transmitted | Recognized | Remarks |
| Function ... | | | |
+---------------------+--------------------+--------------------+---------------------+
|Basic Default | | 1-16 | Memorized |
|Channel Changed | | 1-16 | for every tracks |
+---------------------+--------------------+--------------------+---------------------+
| Default | | 3 | |
|Mode Messages | | | |
| Altered | ****************** | | |
+---------------------+--------------------+--------------------+---------------------+
|Note | | 0-127 | |
|Number | True voice | ****************** | | |
+---------------------+--------------------+--------------------+---------------------+
|Velocity Note ON | | o | |
| Note OFF | | x | |
+---------------------+--------------------+--------------------+---------------------+
|After Key's | | x | |
|Touch Ch's | | x | |
+---------------------+--------------------+--------------------+---------------------+
|Pitch Bend | | o | MS7bits |
+---------------------+--------------------+--------------------+---------------------+
| | | 7 | Volume |
| | | 10 | Panpot (*1) |
|Control | | | |
| | | | |
|Change | | | |
| | | | |
| | | | |
| | |120 | All Sounds Off |
| | |121 | Reset All Ctrls |
+---------------------+--------------------+--------------------+---------------------+
|Prog | | o 0-127 | |
|Change | True # | ****************** | | |
+---------------------+--------------------+--------------------+---------------------+
|System Exclusive | | x | |
+---------------------+--------------------+--------------------+---------------------+
|System | Song Pos | | x | |
| | Song Sel | | o | |
|Common | Tune | | x | |
+---------------------+--------------------+--------------------+---------------------+
|System | Clock | | o | |
|Real Time | Commands | | o | |
+---------------------+--------------------+--------------------+---------------------+
|Aux | Local ON/OFF | | x | |
| | All Notes OFF| | o | |
|Mes- | Active Sense | | x | |
|sages | Reset | | x | |
+---------------------+--------------------+--------------------+---------------------+
|Notes No transmitted messages. |
| *1: Bass only |
| |
| |
+-------------------------------------------------------------------------------------+
Mode 1 : OMNI ON, POLY Mode 2 : OMNI ON, MONO o : Yes
Mode 3 : OMNI OFF, POLY Mode 3 : OMNI OFF, MONO x : No
