Reference
ZOOM RhythmTrak RT-123 MIDI Implementation
1.TRANSMITTED DATA
NONE.
2.RECOGNIZED DATA
1) CHANNEL VOICE MESSAGES
STATUS SECOND THIRD DESCRIOTION
1000 nnnn 0kkk kkkk 0vvv vvvv NOTE OFF (See NOTE 1)
kkk kkkk : Note No.
vvv vvvv : Note Off Velocity (ignored)
1001 nnnn 0kkk kkkk 0000 0000 NOTE OFF (See NOTE 1)
kkk kkkk : Note No.
1001 nnnn 0kkk kkkk 0vvv vvvv NOTE ON (See NOTE 1)
kkk kkkk : Note No.
vvv vvvv : Note On Velocity (not 0)
1011 nnnn 0ccc cccc 0vvv vvvv CONTROL CHANGE
ccc cccc : Control No.
7 Volume
10 Panpot (See NOTE 3)
vvv vvvv : Control Value
1100 nnnn 0ppp pppp —— —— PROGRAM CHANGE
ppp pppp : Program Number (See NOTE 2)
1110 nnnn 0vvv vvvv 0vvv vvvv PITCH BENDER CHANGE (See NOTE 3)
vvv vvvv vvv vvvv Pitch Bend Value
NOTE: nnnn = MIDI Channel Number ( 0000 - 1111 )
1. Note Off Messages on Drum Channel(s) will be ignored.
2. Relationship between Program Numbers and Kit Numbers are assigned as
described in Drum Kits/Bass Program List.
3. Pitch Bend values will be used only MS7bits.
Pitch Bending will be effected continuously only on Bass Channel.
Panpot Controller will also be effected only on Bass Channel.
