45
FUNCTION
Key
Settings
The setting range of the various items controlled with the [FUNCTION] key is described below.
Setting Range Pad 1 pitch: A1 - A2
Pad 2 - 13 pitch: E1 - A4
Sets the pitch of the tones assigned to the pads for a bass program in semitones. You can either shift the
pitch of the entire bass program or the pitch of pads 2 - 13 individually.
■ Shifting the pitch of the entire bass program
Immediately after pressing the [FUNCTION] key and then pad 1 (BASS KEY), the pitch assigned to
pad 1 (A1 - A2) is shown on the display. Use the [VALUE +/-] keys to set the pitch. This will cause
the pitch of pads 2 - 13 to change accordingly.
■ Shifting the pitch of pads 2 - 13 individually
After pressing the [FUNCTION] key and then pad 1 (BASS KEY), hold down one of pads 2 - 13, and
then use the [VALUE +/-] keys to set the pitch (E1 - A4) for that pad. This will not affect the pitch of
other pads.
Setting Range: 0 - 99
Sets the volume for each track in the currently selected pattern over a range of 0 - 99. After selecting this
item, use the [DRUM A], [DRUM B], and [BASS] keys to select the track and then use the [VALUE +/-]
keys to make the setting.
Setting Range: 435 - 445 (Default value: 440)
Allows tuning the bass pitch keys in the range of A = 435 Hz to A = 445 Hz.
[FUNCTION] key items
Shifting bass program pitch in semitones (BASS KEY)
When pad 1 = A2
When pad 1 = A1
The RT-123 stores this setting for each pattern individually when
the [FUNCTION] key is pressed once more to terminate the mode.
HINT HINT
The RT-123 stores this setting for each pattern individually when
the [FUNCTION] key is pressed once more to terminate the mode.
HINT HINT
Setting the pattern/track level (MIX)
Tuning a bass program (BASS TUNE)
