Wayne-Dalton 451 - Manual (Page 3)

3
PRECAST WALL WITH CORNER ANGLE
3” TRACK
PRECAST WALL WITHOUT CORNER ANGLE
3” TRACK
STEEL JAMBS
2” TRACK
PRECAST WALL WITH CORNER ANGLE
2” TRACK
PRECAST WALL WITHOUT CORNER ANGLE
2” TRACK
WOOD JAMBS
2” TRACK
FLUSH
1-1/2”
2” X 6” JAMB IS
RECOMMENDED
1/2”- 5/8”
5/16 X 1-5/8”
LAG SCREW
1” OVERLAP
1-1/2”
1/2”- 5/8”
3/8 X 3” MIN.
SLEEVE ANCHOR
OPTIONAL
MOUNTING
BRACKET
4-3/16”
4-3/4”
3-1/2”
MIN.
SIDE ROOM
1” OVERLAP
1-1/2”
1/2”- 5/8”
5/16 X 1” DRILLING/
TAPPING SCREW
4-3/16”
3-1/2”
MIN.
SIDE ROOM
4”
MIN.
SIDE ROOM
4-3/16”
1” OVERLAP
1-1/2”
1/2”- 5/8”
5/16 X 1” DRILLING/
TAPPING SCREW
3/8 X 3” MIN.
SLEEVE ANCHOR
OPTIONAL
MOUNTING BRACKET
4-15/16”
5-1/2”
4”
MIN.
SIDE ROOM
1” OVERLAP
1-1/2”
1/2”- 5/8”
3/8 X 3” MIN.
SLEEVE ANCHOR
OPTIONAL
MOUNTING
BRACKET
4-15/16”
5-1/2”
4”
MIN.
SIDE ROOM
4-1/2
MIN.
SIDEROOM REQUIREMENTS
1” OVERLAP
1-1/2”
1/2”- 5/8”
5/16 X 1” DRILLING/
TAPPING SCREW
3/8 X 3” MIN.
SLEEVE ANCHOR
OPTIONAL
MOUNTING
BRACKET
4-3/16”
4-3/4”
3-1/2”
MIN.
SIDE ROOM
STEEL JAMBS
3” TRACK
WOOD JAMBS
3” TRACK
1”
1/2”- 5/8”
FLUSH
1”
5/16 X 1” DRILLING/
TAPPING SCREW
2” X 6” JAMB
IS RECOMMENDED
1/2”- 5/8”
5/16 X 1-5/8”
LAG SCREW
1” OVERLAP
4” MIN.
SIDE ROOM
5-1/2”
MIN.
SIDE ROOM
4-15/16” 4-15/16”
5-1/2”
MIN.
