030-300536 Rev. A 178 August 2007
User Guide VersaLink Wireless Gateway (Model 7500)
17.2.7 Transceiver Statistics
In the Advanced Status screen, click Transceiver Statistics. The following screen will be displayed. After you
have viewed the details in this page, click Close to return to the Advanced Status screen.
Transceiver Statistics
Transceiver Revision The transceiver software version number.
Vendor ID Code The CPE Vendor’s ID code for their chipset.
Line Mode The operational mode. Modes supported are No Mode, Multi Mode, T1.413
Mode, G.DMT Mode, and G.LITE Mode.
Data Path The data path used (either Fast or Interleaved).
Transceiver Information-Down Stream/Up Stream Path
DSL Speed (Kbits/Sec) The transmission rate that is provided by your service provider.
SNR Margin (dB) The Signal-to-Noise Ratio (S/N) where 0 db = 1x10 -7 , which inhibits your DSL
speed.
Line Attenuation (dB) The DSL line loss.
Transmit Power (dBm) The transmitted signal strength.
