Verizon 7500 - Manual (Page 165)

030-300536 Rev. A 165 August 2007
User Guide VersaLink Wireless Gateway (Model 7500)
RIPv1 or RIPv2
Transmit The version of RIP to be transmitted. (WAN side RIP never transmits)
Possible Responses:
None
RIPv1
RIPv1 Compatible
RIPv2
RIPv2 Authentication Mode If using RIP V2, you must select the type of authentication to use.
Possible Responses:
None
Clear Text
MD5 (If MD5 authentication, the password)
Advanced
Default Gateway Factory Default = Disabled
If this box is check (Enabled), this feature will determine whether the modem
advertises itself as the default Gateway (i.e., the default route)
RIP Timer Rate Indicates how often to update the local routing table.
RIP Supply Interval Indicates how often to advertise routes to neighbors.
RIP Expire Time Indicates how long routes received from neighbors become invalid, if no refresh
of the route is received.
RIP Garbage Collection Time Indicates how long to advertise invalid routes after they have expired.
After you have enabled RIP and clicked Save, the following pop-up screen will be displayed. Click OK to save and
configure RIP.
