72 - User's Manual
Group: imagepreview_c<0~(n-1)> for n channel products
NAME VALUE SECURITY
(get/set)
DESCRIPTION
brightness 4/4 Preview of brightness adjustment of image
according to mode settings.
saturation -5 ~ 5 4/4 Preview of saturation adjustment of image
according to mode settings.
contrast -5 ~ 5 4/4 Preview of contrast adjustment of image
according to mode settings.
sharpness 4/4 Preview of sharpness adjustment of image
according to mode settings.
videoin_whitebalance auto,
manual
4/4 Preview of white balance adjustment of
image according to mode settings.
videoin_restoreatwb 0, 1~ 4/4 Restore white balance adjustment of image
according to mode settings.
Group: imagepreview
NAME VALUE SECURITY
(get/set)
DESCRIPTION
videoin_whitebalance auto,
manual
4/4 Preview of adjusting white balance of image according
to mode settings
videoin_restoreatwb 0, 1~ 4/4 Restore of adjusting white balance of image according
to mode settings
Group: motion_c<0~(n-1)> for m profile and n channel product
NAME VALUE SECURITY
(get/set)
DESCRIPTION
enable 4/4 Enable motion detection.
win_i<0~2>_enable 4/4 Enable motion window 1~3.
win_i<0~2>_name string[14] 4/4 Name of motion window 1~3.
win_i<0~2>_left 0 ~ 320 4/4 Left coordinate of window position.
win_i<0~2>_top 0 ~ 240 4/4 Top coordinate of window position.
win_i<0~2>_width 0 ~ 320 4/4 Width of motion detection window.
win_i<0~2>_height 0 ~ 240 4/4 Height of motion detection window.
win_i<0~2>_objsize 0 ~ 100 4/4 Percent of motion detection window.
win_i<0~2>_sensitivity 0 ~ 100 4/4 Sensitivity of motion detection window.
