64
• Flush mounting bracket for “in dash” installation.
Contact your Uniden Dealer for information.
Optional Accessories
NMEA Technical Setup
POLARIS NMEA0183 GPS Input Connection
Specification
This section is useful when attaching an external GPS to the POLARIS
radio. Many GPS units have a setup menu to be able to configure the
NMEA0183 serial data output. This output can be used to supply
information to other devices on the vessel, such as the POLARIS DSC
VHF radio, auto pilots, chart plotters, etc.
To setup the GPS to be used with the POLARIS radio, the following
items need to be considered for proper operation:
1. Baud Rate – Set the Baud rate to 4800.
2. Data Bits – Set the Data Bits to 8.
3. Parity – Set the Parity to None.
4. Stop Bits – Set the Stop Bits to 1.
5. GPRMC Command – This command is used by the POLARIS
and includes the UTC Time, Latitude, Longitude, Speed, Direction,
and Date information.
The data amplitude : Over 3.0V
Drive capability : Over 10mA
