6 Configuring the Receiver Using the Keypad and Display
62 SPSx51 Modular GPS Receivers User Guide
Button functions
Use the buttons on the front panel to turn the receiver on and off and to check or
change the receiver settings.
Power button operations
Press the Power button
E
to turn the receiver on and off. In addition, you can tap
E
to return to the Home screen, or hold down
E
to perform the following operations:
Button Name
Function
E
Power
Turns the receiver on and off. See the next section.
F
Escape
Returns to the previous screen or cancels changes being made on a
screen.
L
Enter
Advances to the next screen or accepts changes made on a screen.
J
Up
Moves the cursor between multiple fields on a screen or makes changes
to an editable field.
K
Down
Moves the cursor between multiple fields on a screen or makes changes
to an editable field.
I
Left
Moves the cursor between characters in a field that can be changed.
G
Right
Moves the cursor between characters in a field that can be changed.
Press this button to enter Edit mode.
To …
Hold the
E
button for …
Notes
turn off the receiver
two seconds
The display shows a countdown timer. When the display goes
blank, release the
Power
button.
clear the almanac,
ephemeris, and SV
information
15 seconds
The display show a countdown timer. When the display goes
blank, continue to hold the
Power
button. The display shows a
countdown time to clear the almanac and ephemeris. When
the counter reaches 0, release the
Power
button.
reset the receiver to its
factory defaults and
the default application
file
35 seconds
The display show a countdown timer. When the display goes
blank, continue to hold the
Power
button. The display show a
countdown to clear the almanac and ephemeris. When the
counter reaches 0, continue to hold the
Power
button. The
display indicates a countdown to resetting the receiver. When
the counter reaches 0, release the
Power
button.
force the receiver to
power down
at least 60
seconds
If the reset method above does not work, use this method to
force the receiver to turn off. When the Power LED goes off,
release the Power button.
