NR. CODE DESCRIPION QTY.
1 103 9039 BASE FRAME 1
2 103 9040 UPRIGHT TUBE 1
3 203 9025 UPPER SWIVEL HANDLE BAR (L) 1
4 203 9026 UPPER SWIVEL HANDLE BAR (R) 1
5 203 9027 LOWER SWIVEL HANDLE BAR (L) 1
6 203 9028 LOWER SWIVEL HANDLE BAR (R) 1
7 103 9041 PEDAL TUBE (L) 1
8 103 9042 PEDAL TUBE (R) 1
9 103 9043 OUTER PEDAL POST ( L ) 1
10 103 9044 OUTER PEDAL POST ( R ) 1
11 103 9045 FRONT FOOT 1
12 103 9046 MIDDLE FOOT 1
13 103 9047 REAR FOOT 1
14 103 9048 CROSS FRAME 2
15 103 9048 RAIL 2
16 303 1036 20 AXLE FOR PULLEY 1
17 303 1030 AXLE SUPPORT 1
18 104 9046 PEDAL TUBE SHAFT 2
19 104 9047 BUSHING TUBE 4
20 503 9022 CURVE BRACKET 1
21 653 7072 WASHER FOR PEDAL 2
22 203 4096 FIX HANDLEBAR 1
23 M5*20MM SELF-TAPING SCREW 16
24 M6*14MM ALLEN HEAD SCREW 4
25 M6*53MM SCREW 1
26 M5*12MM ROUND MACHINE SCREW 8
27 M6*10MM ROUND MACHINE SCREW 1
28 M8*15MM ALLEN HEAD SCREW 8
29 M8*20MM ALLEN HEAD SCREW 10
30 M8*42MM ALLEN HEAD SCREW 2
31 M8*58MM ALLEN HEAD SCREW 4
32 M8*63MM ALLEN HEAD SCREW 2
33 M6*12MM SELF-TAPING SCREW 1
34 M6*18MM HEX HEAD BOLT 4
35 M5*1,5MM WASHER 8
36 M8*25MM ALLEN HEAD SCREW 2
37 M8*1,2MM WASHER 30
38 M8*28MM WASHER 2
39 M8*38MM WASHER 4
40 303 1031 AXLE FOR ROLLER 2
41 403 1204 EXTENSION WIRE 1
42 M8 SPRING WASHER 38
43 M8*56MM ALLEN HEAD SCREW 4
44 M8 CURVE WASHER 10
45 3/8” WH NUT 2
46 M6 NYLOC NUT 4
47 M6 NYLOC NUT 1
48 M8 NYLOC NUT 6
49 653 7073 CLIP C17 2
50 523 4072 BEARING 2
51 523 4073 BEARING 4
52 303 1032 PLUG AXLE SUPPORT 6
53 303 1033 PLUG AXLE SUPPORT∮34 4
54 303 1034 PLUG AXLE SUPPORT∮30 4
55 104 9048 BUSHING 8
56 213 1024 OVAL END CAP 1
57 213 1025 END CAP FOR 30 X 70MM TUBE 1
58 213 1026 ROUND END CAP 2
59 213 1027 FIX HANDLEBAR END CAP 2
60 523 4074 ROLLER 2
61 653 1047 ROUND SCREW FOR ADJ HEIGH 6
62 213 1039 TURNING PLATE 2
63 443 4072 BELT 1
64 213 1028 HANDLEBAR END CAP 2
65 173 9056 FRONT SLEEVE 1
66 173 9077 CHAIN COVER (L) 1
67 173 9078 CHAIN COVER (R) 1
68 173 9079 SCREW COVER 2
69 173 9060 FRONT COVER 1
70 173 9061 MIDDLE COVER 1
71 173 9062 COVER FOR ROLLER 2
72 403 1205 SENSOR WIRE 1
73 403 1206 COMPUTER UPPER CABLE 1
74 403 1207 COMPUTER LOWER CABLE 1
75 403 1208 DC WIRE 1
76 363 1021 PEDAL 2
77 303 1035 PULLEY 1
78 213 1029 CAP FOR TURNING PEDAL 2
79 503 4103 METER CLAMP SOCKET 1
80 503 4104 HUB 1
81 503 4105 ADAPTOR SOCKET 1
82 213 1030 FIX HANDLEBAR FOAM GRIPS 2
83 213 1031 HANDLEBAR FOAM GRIPS 2
84 533 4160 MOVING WHEEL 2
85 M5*15MM SCREW 2
86 103 9067 PLASTIC SPACER FOR PCB 2
87 M8*20MM ALLEN HEAD SCREW 8
88 403 1201 20 EMS SYSTEM 1
89 503 4106 SENSOR BRACKET 1
90 403 1198 HAND PULSE SENSOR 2
91 403 4214 HAND PULSE WIRE 2
92 M6*1,2MM WASHER 4
93 235 1069 CONSOLE 1
94 403 1199 MAGNET 9
95 403 9044 CONTROL BOARD 1
96 TRANSFORMER 1
403 0061EU
403 0061US
403 0061UK
403 0061AUS
97 556 0002 TOOL 1
98 556 0002 TOOL 1
99 556 0005 TOOL 1
100 SELF-TAPING SCREW 2
101 M5*12MM SCREW 4
102 M5*30MM SCREW 2
103 M5*20MM SCREW 2
104 M6*1,2MM WASHER 1
105 556 0006 TOOL 1
106 556 0007 TOOL 1
107 M6 SPRING WASHER 4
108 M6*15MM ROUND MACHINE SCREW 2
109 103 9068 PLASTIC SPACER 2
110 M5 SPRING WASHER 8
111 M6*2T SPRING WASHER 2
112 M4*15MM SCREW 4
- 583 9019 OWNER’S MANUAL 1
