Tripp Lite Alternative Power Sources - Manual (Page 15)

15
Specifications
(Hardwired Models)
HARDWIRED MODELS: APSINT2012 APSINT2424
Weight: 17.1 Kg 18.5 Kg
INVERTER
Continuous power (@ 20° C):
2000 W 2400 W
Surge power (5 seconds): 4000 W 4800 W
Efficiency (Full Load): 89% 89%
Minimum DC Fuse Rating: 370A 220A
DC Input Current @ Nominal V DC
Full Load 192 A 112 A
No Load 3 A* 1.8 A*
Nominal Input Volts: 12 VDC 24 VDC
DC Input Voltage Range: 10-15 VDC 20-30 VDC
Nominal Output Volts: 230 VAC ±5% 230 VAC ±5%
Nominal Output Frequency: 50 † Hz ±.3% 50 † Hz ±.3%
BATTERY CHARGER
Charging Capacity DC:
60 A 30 A
Maximum Cable Length 1 ft. 3 ft.
Acceptance Volts VDC: Selectable Selectable
14.4 V**/14.2 V Wet**/Gel 28.8 V**/28.4 V Wet**/Gel
Float Volts VDC (w/gel): 13.3 V (13.6 V) 26.6 V (27.2 V)
Input Voltage AC: 230 V 230 V
Input Current AC: 8.5 A 8.5 A
LINE VAC OPERATION
Minimum Input AC Volts:
Selectable 144**,163, 182 or 201 VAC Selectable 144**,163, 182 or 201 VAC
Maximum Input AC Volts
(Continuous, Charger at Maximum):
Selectable 259** or 264 VAC Selectable 259** or 264 VAC
Maximum Input Current
(Continuous, Charger at Maximum):
17 A 19 A
Input Frequency: 50 Hz ±10% 50 Hz ±10%
Maximum Output AC (Continuous) 8.7 A 10.4 A
Automatic Transfer Time: 4-6 ms 4-6 ms
HARDWIRED MODELS (Cont.): APSINT3636VR
Weight: 25.6 Kg
INVERTER
Continuous power (@ 20° C):
3600 W
Surge power (5 seconds): 7200 W
Efficiency (Full Load): 89%
Minimum DC Fuse Rating: 130A
DC Input Current @ Nominal V DC
Full Load 114 A
No Load 2 A*
Nominal Input Volts: 36 VDC
DC Input Voltage Range: 30-45 VDC
Nominal Output Volts: 230 VAC ±5%
Nominal Output Frequency: 50 † Hz ±.3%
BATTERY CHARGER
Charging Capacity DC:
30 A
Maximum Cable Length 4.5 ft.
Acceptance Volts VDC: Selectable
43.2 V**/42.6 V Wet**/Gel
Float Volts VDC (w/gel): 39.9 V (40.8 V)
Input Voltage AC: 230 V
Input Current AC: 28 A
LINE VAC OPERATION
Minimum Input AC Volts:
Selectable 144**,163, 182 or 201 VAC
Maximum Input AC Volts
(Continuous, Charger at Maximum):
Selectable 259** or 264 VAC
Maximum Input Current
(Continuous, Charger at Maximum):
30 A***
Input Frequency: 50 Hz ±10%
Maximum Output AC (Continuous) 15.7 A
Automatic Transfer Time: 4-6 ms
*Load sense can reduce this to 1/30 of the listed current. **Factory default setting. ***When AVR is boosting incoming current.
† A technician may be able to convert your UPS to receive 50 Hz ±10%power. Consult Tripp Lite for details.
