- 12 -
1.81(46)
Dimensions: inch (mm)
3.29(83.5)
Upside
5-1-3. Installation to a Switch Box
(i) Mounting the Camera to a Switch Box Positioned Normally on a Wall
1. Install the switch box.
2. Set the "Upside" on the base to
the up position.
3. Attach the camera to the switch
box with the four mounting screws.
Mounting Screw x 4
(not supplied)
Switch Box
