2. SPECIFICATION

2.2 OPTION

2- 2

2.2 OPTION

NOTES:
1. Contact TOSHIBA TEC H.Q. or your nearest TOSHIBA TEC representative.
2. Order from TOSHIBA TEC Parts Center or purchase locally.
3. When purchasing memory modules locally, select one having the following specifications.

Maker:

HITACHI Static RAM (OP-9000-SRAM-512KB)

Type:

HM628512ALP-770ns, 600mil 32-pin Plastic DIP (DP-32) (OP-9000-SRAM-512KB)

Option Name

Model No.

or Part No.

Description

Source

LON Connector
TM8P-88P

Part No.
EAJ-0028001

A modular connector used to connect scales
to each other in a LON configuration.

See

Note 2

LON Terminal
Resistor 285D-8P

Part No.
EAJ-0029001

A modular resistor attached to the scales
connected at both ends of the LON
configuration.

See

Note 2

LON Cable
S-STLAN-2P
(200 m/roll)

Part No.
10319100003

An 8-pin telephone cable used with the LON
connectors attached to both ends of the cable.
This cable connects scales to each other in a
LON configuration.

See

Note 2

LON

LON Ferrite Core
ESD-SR-15

Part No.
DDG-0106001

A ferrite core for the LON interface

See
Note 2

I/O PC Board

OP-9000-IOB

An I/O board equipped with the TMCC
interface and PC-AT keyboard interface ports.
It is used to construct a TMCC system and
program PLU data, etc..

See

Note 1

TMCC Cable kit

OP-9000-IOCN-
TMCC

A cable kit for the TMCC interface.

See
Note 1

Memory Module

OP-9000-SRAM-
512KB

DIP type S-RAM to be installed on the MEMO
PC board for memory expansion. When
expanding the memory, install the two
modules as one set.

See
Note 1
and 3

10 Base T (LAN) Interface
Board (H-9100N only)

OP-9000N-LAN

This board enables the H-9100N to be used in
a LAN network.

See
Note 1
