TVP-224HR User’s Guide

100

10.8 Dial in PLAR (Hotline) – TVP-224HR / TVP-224HR

Trendware VoIP Gateways are capable of automatically calling or forwarding an
incoming call from the Internet or PSTN line onward to another remote destination.

The following three examples illustrate these topographies:

1. FXS to FXO PLAR
2. FXO to FXS PLAR
3. FXO to FXO PLAR

Case 5: PLAR (Hotline) FXO to FXS example

Site A

Site B

This could be a call
placed from any outside
PSTN number
