Figure 3-2: Sensor Installation.

3.5

Micro-Fuel Cell Sensor Installation or Replacement

The 3160 comes with the Micro-Fuel Cell(s) already installed. When installing or

replacing the cells, remember to inspect the replacement sensor for leaks or damage. See
Figure 3-2.
