Tiger Products Co., Ltd COUGAR BOOM 7X30 - Manual (Page 149)

Cougar Common Section 6 - 19
50” FLAIL MOWER ASSEMBLY
ITEM PART NO. QTY. DESCRIPTION
- 06742078 AVAIL FLAIL, BOOM,50,CPLT ASSY
1 06320170 1 CUTTER HEAD BONNET
3 34783
AVAIL
TBF50,BRUSH,KNIFE ASSY
3A 34784
AVAIL
TBF50,GRASS,KNIFE ASSY
4 TF3405 1 GROUND ROLLER
5 TF3406 1 GROUND ROLLER TIE ROD
6 TB1006A 2 DEFLECTOR FLAP
7 TB1008 1 FLAP RETAINING BAR
8 TF3001 2 SKID SHOE
9 TF3407 2 GROUND ROLLER ADJUSTMENT BRACKET
10 TF1022 2 FLANGE BEARING 1 3/8”
11 TF1018 2 FLANGE BEARING 2 3/16”
12 TF3007A 1 COVER PLATE
13 TF1040 1 CUTTER SHAFT GUARD
14 41725.01 24 BUSHING,1ODX5/8ID
15 34782 24 CLEVIS,BRUSH
15B 34781 24 CLEVIS,GRASS
19 34780 24 BRUSH KNIFE STANDARD
19B 33714 48 HD KNIFE - OPTIONAL
20 34786 24 CAPSCREW 9/16” X 3 1/2”
22 6T2419 24 HEX NUT 9/16”
23 21838 1 CAPSCREW 3/4” X 3 1/2”
24 21825 1 HEX NUT 5/8”
25 06530218 8 CAPSCREW 1/2” X 1 3/4”
26 21731 6 CAPSCREW 1/2” X 1 1/2”
27 21990 18 LOCKWASHER 1/2”
28 21725 10 HEX NUT 1/2”
29 6T2270 12 PLOWBOLT 3/8” X 1”
31 21630 4 CAPSCREW 3/8” X 1”
32 21988 3 LOCKWASHER 3/8”
33 21625 19 HEX NUT 3/8”
34 22016 26 FLATWASHER 3/8”
35 21633 9 CAPSCREW 3/8” X 1 3/4”
36 6T7031D 4 PLOW BOLT 1/2” X 1 1/2”
37 6T2330 8 CAPSCREW 7/16” X 1 1/2” SOCKET HEAD
38 6T1023R 2 NYLOCK NUT 1 1/8” NF
39 TF1032 1 FLANGE BEARING GREASE HOSE
40 31204 2 SETS STRING GUARD SET (2 PIECES PER SET)
