Cougar Common Section 6 - 13
60” ROTARY MOWER ASSEMBLY
ITEM P/N QTY. DESCRIPTION
1 06320160 1 DECK,TRB60,ROT,CPLT
2 06320162 1 SHIELD,TRB60,ROT
3 33777 2 SKID SHOE,50" RTRY
4 06401245 2 SKID SHOE,TRB60,ROT
5 33776 1 MOTOR MOUNT,PLATE,50" RTRY
6 06504011 1 MOTOR,(M365-1 1/2" GEAR)
7 06520238 2 FLAP, DEFLECTOR
8 06t0823 1 BAR, FLAP, TM60
9 6T1024H5 1 SPINDLE ASSY, CPLT, HD, 5/8 HOLES
10 6T1033 1 COVER,COUPLING
11 6t1029 1 CHAIN,COUPLING (5016)
12 TF1124 1 KEY,5/16 SQ X 1-1/2 RND
13 21223 1 SPROCKET, 1-1/4" BORE
14 33879 6 CAPSCREW, 3/4 x 2 1/4,NF GR 8
15 33880 12 FLATWASHER,3/4",GR 8,SAE
16 6T2413 6 HEX NUT,3/4,NF,GR 8
17 33785 1 CYL,1 1/2 x 8
18 06420139 1 PIN,HINGE,TRB60,ROT
19 6T3207 1 GREASE ZERK,1/4"
20 21633 11 CAPSCREW, 3/8x1 3/4,NC,GR8
21 21727 4 NYLOCK NUT, 1/2
22 21730 7 CAPSCREW, 1/2 X 1 1/4,NC
23 21731 7 CAPSCREW, 1/2 X 1 1/2,NC
25 21733 4 CAPSCREW, 1/2 x 2,NC
26 22016 31 FLATWASHER,3/8",GR8
27 6T3017 2 ROLLPIN,3/16" X 1"
28 33924 2 RETAINING RING,EXTERNAL,1/2"
29 33984 2 PIN,SHIELD,50"
30 RD1032 2 PIN,LYNCH 1/4" X 2"
32 6T2290 4 CAPSCREW,5/8x2,NF GR 8
33 6T2408 4 HEX NUT, 5/8, NF
34 33764 8 FLATWASHER,5/8",GR 8,SAE
35 33779 1 PLATE,COVER,KNF HOLE
36 33881 2 CAPSCREW,FLG, 3/8 x 3/4,NC
37 6t2270 20 PLOW BOLT,3/8x1,NC,GR5
38 21625 20 HEX NUT,3/8",NC
39 06533004 4 FLATWASHER
40 TB3010 1 BUSHING
41 TF4852 2 FLANGE KIT
42 06500458 2 HOSE,1x95, PRESSURE (RED DECAL STRIP)
06500458 * HOSE,1x95, RETURN (BLUE DECAL STRIP)
43 33601 1 HOSE,1/4x111
44 06500480 1 HOSE,1/4x107
45 06503057 2 ADAPTER,1/4ORBx3/8MJ
