Page 107
JD 7X30 COUGAR Parts Section 5-5
TRACTOR MOUNT KIT - MAIN FRAME
ITEM PART NO.
QTY.
DESCRIPTION
1
06300105
1
MNFRM,JD7130,SBR,OS BOOMRST
2
06300060
1
MNT,HYDRO TANK,JD6000
3
21833
6
CAPSCREW,3/4 X 2-1/4 NC
4
33880
37
FLATWASHER,3/4,GR 8,SAE
5
21825
6
HEX NUT,3/4 NC
06700090
1
TANK,RES,JD6000,ASSY
6
06380012
1
TANK,RES,JD60004WD(34GAL)
7
06505044
1
FLTR ASSY,IN-TANK CPLT,SAE10M
*
35259
1
FILTER ELEMENT
8
06505067
1
SIGHT GAUGE,JD6000,TANK,34GAL
9
22018
2
FLATWASHER,1/2,WIDE
10
21725
2
HEX NUT,1/2 NC
11
21627
4
NYLOCK NUT,3/8 NC
12
06505077
1
CAP,BREATHER,O-RING
13
31731
21
CAPSCREW,20MMX50MM(2.5 PITCH)
14
27281
2
CAPSCREW,20MMX60MM(2.5P)GR10.
15
31722
19
HEX NUT,20MM(2.5P)GR 10.9,FLN
16
34998
1
SPACER,DRIVESHAFT,JD72-7510/20
17
34999
1
DRIVESHAFT,U-JOINT,JD62-7510/2
18
21658
1
CAPSCREW,7/16 X 2 NF,GR8
19
34848
1
HEX NUT,7/16 NF,GR8 (STOVER)
20
21680
4
CAPSCREW,7/16 X 1-1/4NC GR5
21
21989
4
LOCKWASHER,7/16
22
23113
4
CAPSCREW,10MMX30MM(1.5 PITCH)
23
32691
4
LOCKWASHER,10MM
24
23152
1
PUMP,P350-1 3/4 GEAR
25
34993
1
PUMP MNT,JD,U DRIVE
26
21732
4
CAPSCREW,1/2 X 1-3/4 NC
27
21990
4
LOCKWASHER,1/2
28
21725
4
HEX NUT,1/2 NC
29
24860
4
CAPSCREW,20mmx40mm(2.5P)10.9
30
22014
1
FLATWASHER,1/4
31
32519
1
NUT,WING,1/4-20 UNC
32
06410352
1
CHANNEL,MNT,TANK,TIE-BOLT
33
06380014
2
TIE BOLT,SIDE TANK,HYDRO
34
33764
2
FLATWASHER,5/8,GR 8,SAE
35
6T0649
1
FILTER GAGE
36
TF4888
1
STREET ELBOW,1/8 X 90
37
06300123
1
AXLE BRACE,RH
38
21993
2
LOCKWASHER,3/4,GR 8
39
24881
6
LOCKWASHER,20MM
JD73-7530 TRACTORS
40
27281
6
CAPSCREW,20MM x 60MM,2.5P
JD71-7230 TRACTORS
40
32703
6
CAPSCREW,20MM x 100MM,2.5P
41
06400173
2
SPACER,AXLE
