Supported DIMM Qty (8)+(8) DIMM slots
DIMM Type / Speed
U/RDDR3 & LV RDDR3, 800/1066/1333 MHz
Capacity
Up to 256GB (total)
Memory channel
4 Channels per CPU
Memory
Memory voltage
1.5V or 1.35V
PCI-E
(2) PCI-E Gen.2 x16 slots
Expansion Slots
Recommended TYAN
Riser Card
M2091, PCI-E x16 1U riser card (left) and M2091-R, PCI-E x16 1U
riser card (right)
Recommended
Barebone / Chassis
2U Barebone
GT24-B8236
Port Q'ty
(3)
LAN
Controller
Intel 82574L / Intel 82576EB
Connector
(1) Mini-SAS (4-port) + (2) SATA
Controller
AMD SP5100
Speed
3.0 Gb/s
Storage
SATA
RAID
RAID 0/1/10/5 (Promise Integrated RAID)
Connector type
D-Sub 15-pin
Resolution
1600x1200@60Hz
Graphic
Chipset
Aspeed AST2050
USB
(8) USB2.0 ports (3 at rear, 4 via cable, 1 type A onboard)
COM
(2) ports (1 at rear, 1 via cable)
VGA
(1) D-Sub 15-pin VGA port
RJ-45
(4) GbE ports
Power
ATX12V / SSI EEB spec. 2008 / Universal 24-pin + 8-pin + 8-pin
power connectors
Front Panel
(1) 2x12-pin SSI front panel header
Input /Output
SATA
(1) Mini-SAS connector & (2) SATA-II connectors
Chipset
Winbond W83793G
Voltage
Monitors voltage for CPU, memory, chipset & power supply
Fan
Total (8) 4-pin headers
Temperature
Monitors temperature for CPU & system environment
LED
Fan fail LED indicator / Over temperature warning indicator / Fan &
PSU fail LED indicator
System Monitoring
Others
Watchdog timer support
Onboard Chipset
Onboard Aspeed AST2050
AST2050 IPMI Feature IPMI 2.0 compliant baseboard management controller (BMC) / USB
2.0 virtual hub / BIOS update
Server Management
AST2050 iKVM
Feature
24-bit high quality video compression / Dual 10/100 Mb/s MAC
interfaces
Brand / ROM size
AMI / 4MB
BIOS
Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3 /PXE boot / ACPI
2.0 power management /Power on mode after power recovery /
User-configurable H/W monitoring
Form Factor
SSI EEB
Physical Dimension
Board Dimension
12"x13" (305x330mm)
Operating System
OS supported list
Coming soon
FCC (DoC)
Class B
Regulation
CE (DoC)
Yes
Operating Temp.
10° C ~ 35° C (50° F~ 95° F)
Non-operating Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
Operating
Environment
In/Non-operating
Humidity
90%, non-condensing at 35° C
RoHS
RoHS 6/6 Complaint
Yes
Motherboard
(1) S8236 Motherboard
Manual
(1) User's manual / (1) Quick Ref. Guide
Installation CD
(1) TYAN installation CD
I/O Shield
(1) I/O Shield
Package Contains
Cable
SATA
(2) SATA signal cables / (1) Mini-SAS cable
Optional accessories
Riser Card
M2091-R, PCI-E x16 1U riser card (right) / M2091, PCI-E x16 1U
riser card (left)
